Competitive High quality wheel loader L968F

Product Detail

Advantage introduction : Reliable 1、The wheel loader is equipped with Weichai WD10G240E202 engine which features high power reserve, high torque, strong power, low fuel consumption, high quality, low emission and high reability. 2、VRT200 gearbox is adopted with front four and rear four gear positions to render better transmission efficiency and larger transmission ratio of forward positions 1 and 2 owing to the one additional position, and its comprehensive efficiency is increased by over 8%。 3 Reinforced drive axle is adopted with strengthened design, strict technology and guaranteed quality. The rear axle adopts the swing type support with improved reliability, large bearing capacity and service life increased by 50%. 4、The new generation of brand new optimized front and rear frames are adopted with reliable VOLVO technological reliability, rational distribution of load, rational structure and twofold fatigue life. 5、The working hydraulic system adopts high-end Parker multiway valves and Permco working pumps which are reliable and highly efficient. 6、Steel engine hood produced using automotive grade molds is adopted. It adopts the streamlined structure with surface welded points removed, making it look attractive and magnificent. The molded balance iron employs a more powerful shape to provide high reliability and strength. Energy efficient The electric control high pressure common rail engine is adopted with torque increased by 12% to provide better power performance. Comfortable 1、Compared to the mechanical engine, the electric control engine is characterized by low noise and small vibration, thus increasing the comfort during operation and driving. 2、The new generation cab is adopted with space increased by 15% to enhance safety and comfort. The attractive curved front windshield provides a broad view. Convenient 1、The engine hood and heat dissipation hood adopt the large opening design to provide larger space for maintenance. 2、The oil cylinder adopts a unified design and the seals have a universal height to facilitate storage of accessories and maintenance. 3、Electric system centralized control mode is adopted. The fuse and relay of the entire machine are installed in a centralized control box to facilitate inspection and maintenance.

Overall dimension
LWH	868032003470mm
Wheel base	3400mm
Min. ground clearance	530mm
Max. dumping height	3250mm
Dumping distance	1090mm
Dumping angle	45
wheel tread	2250mm
steering angle	38
horizontal crossing radius	7140mm
Min. turning radius	6062mm
Overall parameters
Backet capacity	3.5m3(optional 3.0-5.0)
Rated load	6000kg
operating weight	19950kg
Max. tractive force	180kN
Max. breakout force	210kN
Tipping load	128kN
Engine
Model	WD10G240E201
Type	Inline, watercooled, dry cylinder liner, direct injection
Rated power	178kW
Rated speed	2200r/min
Engine displacement	9726ml
Max. torque	1000N.m
Emission standard	GB 20891-2007(China Phase II)
Min. fuel-consume ratio	230g/kw.h
Transmission system
Torgue converter	single-stage three-element single-turbine hydraulic torque converter
Transmission type	Axis-fixed electro-hydraulic transmission
Gears	Forward 4 reverse 4
Hydraulic system of working device
Type	Hydraulic pilot control
total time	10.3s
Brake system
Service brake type	Air over hydraulic disc type
Parking brake type	Electric pneumatic caliper disc type
Steering system
Type	Load sensing full hydraulic articulated steering
System pressure	21 Mpa
Fill capacity
Fuel	350L
Hydraulic oil	220L
Engine	20L
Transmission	28.4L
Drive axle	Forward 40L+ reverse 40L
Braking system	4L
